AmScope MU Series 5.0MP USB 3.0 Color CMOS C-Mount Microscope Camera with Reduction Lens

This 5MP USB3.0 high speed microscope digital camera has a unique design that comes with a reduction lens, a USB cable and two adapters. The high speed digital camera captures still microscopy images, streams real time live videos on your computers, and is compatible with Windows 8.1/10/11, Mac OSX, and Linux. The user-friendly software for Windows offers advanced features including Stitching, EDF (Extended Depth of Focus) and video recording. Live video and still image capture can be set in different resolutions simultaneously. The reduction lens gives larger field of view.

The software included allows you to make notes, shapes and watermarks with ease. You can analyze, present, and share images of samples and specimen by simply plugging one end into your computer's USB3.0 port, and the other on your microscope's eye-tube or trinocular port. Featuring built-in C-mount compatibility and 23mm reduction lens adapter, our camera can be attached to any instrument with a C-mount or a 23mm, a 30mm and a 30.5mm photo port. The camera is equipped with CMOS color sensor, and comes with a high-speed USB cord, four mounting sizes (23mm, 30mm, 30.5mm, and C-mount), and instructions.

Sensor

Sensor	Sensor Type	Sensor Size	Pixels	Pixel Size	Shutter
Aptina MT9P006	CMOS (color)	1/2.5" format (5.70mm x 4.28mm, diagonal 7.13mm)	5M	2.2µm x 2.2µm	Rolling Shutter

Sensitivity ?	Dynamic Range	SNR	Binning
1.76v / lux-sec (550nm)	67.7dB	38.5dB	1x1, 2x2, 4x4

Camera

Frame Rate(s)	Connectivity	Lens-mount	Compensating Lens	Spectral Range
14.5fps @ 2560x1922, 39fps @ 1280x960, 101fps @ 640x480	USB 3.0	C-mount	0.5X	380-650nm (with IR-filter)

Operating Temperature	Storage Temperature	Operating Humidity	Compatibility
-10°C~50°C	-20°C~60°C	30~80%RH	Windows (32/64 bit) 8.1/10/11, Mac OSX, Linux

Software

OS Requirements	Windows (32/64 bit) 8.1/10/11, Mac OS 10.8+, Linux kernel 3.13+
Hardware Requirements	Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB3.0 port for maximum speed
Features	Windows Version Live video preview Captures still images and video Time-lapse capture Exposure and white-balance controls Dark-field correction Digital binning Image processing Measurement tools, including lines, arcs, polygons Segmentation and counting tools Image-stitching, extended depth-of-field, HDR Fluorescence color-mapping Mac/Linux Versions Live video preview Captures still images and video Exposure control Color adjustment Measurement tools, including lines, arcs, polygons

Packing List:

One 5MP USB3.0 Digital Camera

One Reduction Lens

One 6' (1.8m) USB Cable

Two Adapters: 30mm and 30.5mm

One CD with Software and User's Instructions
